MoirePy: Twist It, Solve It, Own It!

MoirePy is a FOSS Python library for simulating moire lattices with a clean, highly Pythonic API.

It is designed to be easy to use while remaining fully flexible. You can define custom lattice geometries, program arbitrary hopping functions, and build tight-binding Hamiltonians in both real space and k-space, with support for open (OBC) and periodic (PBC) boundary conditions. Generated Hamiltonians can also be exported to tools like Kwant for further analysis.

• Documentation: https://jabed-umar.github.io/MoirePy/

• Github Repository: https://github.com/jabed-umar/MoirePy

• PyPI page: https://pypi.org/project/moirepy/

---

Why MoirePy

• Define anything: No restrictions on lattice geometry or orbitals
• Pythonic API: If you know Python, MoirePy is intuitive
• Custom hoppings: Fully programmable intra/inter-layer couplings
• Real-space + k-space: Both supported natively
• OBC + PBC: Switch boundary conditions easily
• Kwant-compatible: Export Hamiltonians for further analysis
• Fast construction: Efficient neighbour search using KDTree
• Reproducibility-first: Designed to replicate known results and papers

---

Installation

pip install moirepy

---

Quick Example: Twisted Bilayer Graphene

import numpy as np
import matplotlib.pyplot as plt
from moirepy import BilayerMoireLattice, HexagonalLayer

# Define a twisted bilayer moiré lattice
lattice = BilayerMoireLattice(
    latticetype=HexagonalLayer,
    # you choose the next 4 values based on the twist angle using this tool:
    # Angle-Value Calculator: https://jabed-umar.github.io/MoirePy/theory/avc/
    ll1=3, ll2=4, ul1=4, ul2=3,
    n1=1, n2=1,
)

# Visualize the lattice
lattice.plot_lattice()
plt.show()

ham = lattice.generate_hamiltonian(
    tll=1, tuu=1,
    tlu=1, tul=1,
    tlself=0, tuself=0
)  # returns scipy sparse matrix

print(ham.shape)

---

Philosophy

MoirePy does not try to enforce what is "physically valid".

If you want:

• unusual lattices
• non-standard couplings
• high orbital counts

you are free to do so.

The library gives you control. You decide what makes sense.

---

Contributing

Contributions are welcome.

• Report bugs or request features via issues
• Submit pull requests for improvements
• Add examples, tutorials, or benchmarks

A detailed contributing guide will be added soon.

---

Citation

If you use this work in research:

@software{MoirePy2025,
  author = {Mukhopadhyay, Aritra and Umar, Jabed},
  license = {MIT},
  title = {{MoirePy: Python package for efficient atomistic simulation of moiré lattices}},
  url = {https://github.com/jabed-umar/MoirePy}
}
